Bifold Door Sizes: A Practical Guide for Patio and Exterior Openings

Luxury Patio Bifold Door interior door

Bifold door sizes come down to three things: the total width, the height, and how many panels fold to each side. Once you can read those three numbers, comparing doors gets much easier. I’m Reza Khoylou, and after more than 15 years in the door business, I’ll walk you through how our sizes work and how to pick the right one for your opening.

This guide covers exterior patio bifold doors, like the ones we ship from Thousand Oaks, California. Interior closet bifold doors are a different, much smaller product, so the sizes below don’t apply to them.

How Bifold Door Sizes Are Listed

Every listing follows the same pattern: width by height, in inches, followed by a configuration code. For example, 120″ x 96″ (1L3R) is a door 10 feet wide and 8 feet tall.

The code tells you how the panels fold. The number before each letter is how many panels fold to that side:

  • 3L or 3R: three panels, all folding to the left or to the right.
  • 1L3R: four panels, one folding left and three folding right.
  • 5L or 5R: five panels, all folding to one side.
  • 3R3L: six panels, three folding to each side, opening from the center.
bifols door

Standard Bifold Door Sizes at a Glance

Our stock outswing bifold doors come in widths from 72 to 216 inches, in two heights: 80 and 96 inches. Divide the total width by the number of panels and you get the width of each panel, which in our stock sizes falls between 24 and 36 inches.

Width x HeightPanelsConfigurationsPanel widthListed price
72″ x 80″33L / 3R24″$2,995
96″ x 80″33L / 3R32″$3,895
108″ x 80″33L / 3R36″$4,450
96″ x 96″33L / 3R32″$4,495
120″ x 80″41L3R / 1R3L30″$4,850
108″ x 96″33L / 3R36″$4,995
120″ x 96″41L3R / 1R3L30″$5,650
144″ x 80″41L3R / 1R3L36″$5,995
168″ x 80″55L / 5Rabout 34″$6,795
144″ x 96″41L3R / 1R3L36″$6,995
192″ x 80″63R3L32″$7,695
168″ x 96″55L / 5Rabout 34″$7,995
192″ x 96″63R3L32″$9,995
216″ x 96″63R3L36″$10,800

Prices are as listed on our site in October 2026 and can change, so confirm on the product page. Inswing versions are listed by panel count: 3, 4, 5, and 6 panels.

You can see what’s in stock right now, in black and white, on our bifold doors page.

Choosing Bifold Door Sizes by Room

Width is mostly a question of how much of the wall you want to open. These ranges are a good starting point:

  • Kitchens and smaller rooms: 72 to 108 inches, three panels. Easy to operate and a good fit for a patio next to a kitchen.
  • Dining areas and bedrooms: 96 to 144 inches, three or four panels. A comfortable opening without taking over the wall.
  • Living rooms and large openings: 144 to 216 inches, four to six panels. This is where a bifold door really changes how the room works.

Bifold Door Sizes: 80 Inches or 96 Inches Tall?

An 80-inch door matches a standard door height. A 96-inch door suits higher ceilings and gives a taller, more open look. If your opening is already 96 inches tall, or your ceiling allows it, the taller option makes the glass feel less boxed in. The price difference between the two is shown in the table above.

Outswing, Inswing, and the Space the Panels Need

When the doors fold open, the panels stack somewhere. Outswing doors stack outside on the patio. Inswing doors stack inside the room. More panels mean a deeper stack, so a six-panel door needs more clear space beside the opening than a three-panel one.

Before you choose, check the wall space on both sides of the opening, indoors and outdoors, and think about where furniture, planters, or railings sit. If you’re deciding between a bifold and a different style, our Bifold and Patio Doors page compares the options.

How to Measure for Bifold Door Sizes

  1. Width: measure the opening at the top, middle, and bottom. Use the smallest number.
  2. Height: measure on the left, center, and right. Again, use the smallest.
  3. Check the floor and the header: note whether they are level and whether the opening is square.
  4. Note obstructions: beams, windows, lights, or walls near the opening.
  5. Take photos: a few photos from inside and outside help us confirm fit quickly.

The size in a listing is the door size. Send us your opening and we’ll confirm the best fit before you order. For a step-by-step walkthrough, read How to Measure for Bifold Doors.

When Standard Bifold Door Sizes Don’t Fit

If your opening falls between stock sizes, or you want a specific panel layout, our Custom Bifold Doors are built around your measurements. Custom orders take longer than stock and generally cost more, so it’s worth deciding early. If you’re still weighing the budget, our guide to what bifold doors cost explains what drives the price.

Bifolding Doors

Common Questions About Bifold Door Sizes

What are the standard bifold door sizes for a patio?

Our stock sizes run from 72 to 216 inches wide, in heights of 80 and 96 inches. Widths include 72, 96, 108, 120, 144, 168, 192, and 216 inches.

How wide is each panel?

Divide the total width by the number of panels. In our stock configurations, each panel is between 24 and 36 inches wide.

What does 1L3R mean?

It describes a four-panel door: one panel folds to the left and three fold to the right. Codes like 3L, 5R, and 3R3L work the same way.

Are closet bifold door sizes the same?

No. Closet bifold doors are an interior product and much smaller. The sizes in this guide are for exterior patio doors.

Can I order a size that isn’t listed?

Yes. Custom sizing is available for non-standard openings, with a longer lead time than stock.
